CHECKED UNDER THE HOOD:
1. Before Road test/hood open/trunk open
2. Primary and secondary hood latch operation
3. Radiator and cap
4. Hoses and clamps
5. Air filter
6. Change Oil filter
7. Drive belt tension and condition
8
. Change Engine oil
9. Coolant
10. Power steering fluid
11. Brake fluid
12. Clutch fluid*
13. Fill windshield washer fluid
14. I/C water bottle (filled less than
½
full during cold
weather)*
15. Clean battery (mounting, cables, and ground straps)
16. Speci
fic gravity
17. Electrolyte level
18. Load test
19. Spare tire pressure/ tool kit/ jack and handle
20. Replace front & rear wiper blades
CHECKED IN INTERIOR OF VEHICLE:
21. Insert key in ignition/chime
22. Key "ON"/ check dash warning lights
23. Turn "ON
" rear defogger/ check indicator
24. Windshield wipers and washer front/ rear check*
25. Headlights high/low alignment
26. Dash illumination control and display
27. Head light leveler operation*
28. I/C water spray operation*
29. Turn headlights to park po
sition
30. Hazard flashers
31. Reverse lock out check*
32. Shift Transmission to reverse/ set parking brake
check adjustment if necessary
33. Clutch/brake pedal freeplay*
34. Seat belts/warning lights
35. Check for proper movement and operation of both
fro
nt seats
36. Cold weather package operation (heated seats,
mirrors, and windshield)
37. Fuel filler release
38. Lighter and ashtray*
39. Power outlet*
40. Trunk release*
41. DTC check using Select Monitor
42. Steering column parking lamp switch operation
4
3. Sound horn
44. DCCD display and manual mode operation (reset to
automatic mode)*
CHECKED OUTSIDE OF VEHICLE:
45. Fog lamps/aim*
46. Turn signals (front & rear)
47. Parking lamps
48. License plate lamps
49. Brake and high mount stop lamps
50. Tail lamps
51. Reverse lamps
52. All front lamps
53. Fuel filler cap operation
CHECKED WITH DOOR OPEN / IGNITION OFF:
54. Hazard flashers/parking lamps (door open/ignition
"off")
CHECKED IN VEHICLE / IGNITION ON:
55. Turn signals/indicator lamps
56. Brake lamps
57.
Remote mirror operation L/R
58. Passenger airbag on/off and seatbelt warning light*
59. Set clock
60. Steering lock/tilt
61. All seat adjustments
62. Power window operation
63. Sunroof operation
64. Door locks
65. Map/dome lights
66. Radio/CD
-
set statio
ns
CHECKED OUTSIDE VEHICLE WITH KEY:
67. Rear defogger
68. Door locks & door closing operation (key
number/security code recorded)*
69. Rear seat belts
70. Security system*
71. Child safety door locks (left unlocked)
72. Door entry lights*
CHECKED WITH
VEHICLE RAISED / ON LIFT:
73. Tire pressure, tread depth, orientation and condition
74. Tire set match documented
75. Wheel, wheel cover, and trim check
76. Check brakes, rotors, and calipers for specified
parameters
77. Wheel cylinders*
78. Axle seals
79.
Lug nut torque
80. Fluid leak check
81. Complete exhaust system
82. Steering linkage
83. Struts
84. Axles
85. Bolts/bushings/fasteners
86. Rear differential fluid level check and top off
87. Other fluid leaks/damage
CHECKED WITH VEHICLE LOWERED:
88. TP
MS warning light check (should be
off)*
89. Engine performance (cranking, idle, accel., etc.)
90. Transmission performance and warning lights
91. Clutch operation*
92. Clutch safety switch operation*
93. Steering wheel alignment
94. Steering performance (r
eturn, free
-
play, tracking)
95. Wheel balance (absence of vibration)
96. Brake operation
97. Gauges/speedometer/ odometer operation and readings
98. Turn signal operation and cancellation
99. Cruise control operation
100. Vent/heater/A/C operation
101. Che
ck for squeaks, rattles, vibrations, and wind noises
102. Tachometer alarm operation and reset*
103. Hill Holder operation*
104. VDC off switch*
105. Check that all keys start the engine
106. Check for unusual noises
107. Parking brake operation
108. Emiss
ions check as required by state or local laws
109. Re
-
check coolant, power steering and ATF levels
110. Re
-
check DTC
111. Check leaks under vehicle
112. Electric cooling fans check
113. Steering wheel
114. Dash pad/instrument panel
115. Headliner
116. Pass
enger's sunvisor
117. Passenger's side door trim panel
118. Passenger's seat upholstery and trim
119. Glove box
120. Carpet
121. Floor mats
122. Center console, cup holder and arm rest
123. Driver's sunvisor
124. Driver's side door trim panel
125. Driver's
seat upholstery and trim
126. Back of front seats
127. Package shelf*
128. Rear carpet
129. Rear cup holder
130. Floor mats
131. Side door trim panels
132. Rear seat upholstery and trim
133. Trunk/cargo area trim
134. Front bumper
135. Hood
136. Driver's
side body panels
137. Passenger's side body panels
138. Door sills and jambs
139. Roof
140. Trunk/tailgate
141. Rear bumper
142. Glass
143. Other plated or painted parts
144. Overall paint condition
145. Engine compartment
146. Trunk/cargo area
147. Interi
or
148. Exterior
149. Glass
150. Door sills and jambs
151. Decal removal
152. License plates and frames
